Camera Module
Poly I Camera
HA144-05
HA144-05
Product Specification
| Product Function | HD Polyi Camera |
|---|---|
| Power spec | DC 12V ±3V |
| Current Consumption (12V) | Max. 150mA |
| Pixel Size | 1/3.7”/(3um) |
| Resolution | 1280 x 720 pixels |
| F Number | F/NO = 2.0 |
| FOV (Field of View) | FOV(H) 144degree, FOV(V) 112 degree |
| Frame rate(YUV) | 30 fps |
| Max Dynamic Range | 77dB |
| Operating Temperature | -40 to +85 ℃ |
| Storage Temperature | -40 to +90 ℃ |
| I/O | TVI/AHD |
| Product size | 23mm *23mm*29mm (L*W*H) |
| Camera Head Water & dust resistance (not include connector) | IP68 |
